Carbon Zapp MTBRx

0.00 EUR Get the consultation

Available modifications

MTBR-X-Pack 1

'Exclusive Package Includes: [(AZO.B4M, CRP_HPOUT2, CRp -IP.3 KIT)x1], [(SVI.01, BCI.01, CZI.01, BCN.B, DFI.01, DFI.02, BPI.01, DEU.01, DGXS-A, DGXS-B, DG2P-A, DG3P-A, CZ-007356) x 4, VDCP.01x2]

0.00 EUR
MTBR-X Pack 2

Exclusive CRDi Coding Package Includes: [(BC.01, DLC.03, DNC.04)x1], RSPx4, CZ-007101x1

0.00 EUR
MTBR-X-Pack 3

Exclusive Specialists CRDi coding & CRp Package Includes: [(BC.01, DLC.03, DNC.04, VCV.S, CRp-VDD, CRP-CP4.KIT.01, CPN5.01-KIT, CRp.VDO-EU6.KIT, CRP.DNC-HP5.KIT, ZME-CPN5-01, VCVA.01, VCVA.02, VCV.D1-KIT, CZ-007101])x1], [(CZ-007359, RSP)x4], CZ-007156x3,

0.00 EUR
MTBR-X Pack VDO

'Exclusive VDO Authorized Package Includes: [(VC.05, VDO.AUTH)x1], [(CZ-007359, RSP)x4, CZ-007101x1] [UP TO S/N #4419 REQUIRED TO BE ORDERED WITH CZ-007350]

0.00 EUR

The Innovative Standalone Solution for the Diesel Specialist, capable to test every Automotive, Commercial, Industrial and Marine Injection System available in the market today.

CARBON ZAPP MTBR-E

You can find out the cost of equipment by sending a request in the form at the up right.

Overview of the New MTBR-X

Precise, repeatable and rapid Diesel & Gasoline Components Testing

Pump Testing

• 5-15 minutes testing time per pump

• CRp / GDp Pump (All Brands and Types).

• Capable for all EU6 technologies with Sync Operation such as Denso HP5, Bosch CP4-EU6, VDO EU6 technology and more...

• Heavy-Duty CR pump (CPN5S2, CAT, Cummins etc.)

Injectors Testing & Coding

• 6-12 minutes testing and coding* time for 4 injectors

• CRi / CRiN / GDi injectors (All Brands and Types).

• Capable for all EU6 technologies such as VCC and NCC technology, iART, PCRS5,

• XPI, F2E, F2P, F2R Injectors pumps and more...

• CRIN 4.2 Heavy Commercial-Vehicle injectors

• Large Diesel Engine CRiN injector (QSK, MTU, L ’Orange, etc...)

HEUi Testing & Coding

• 6-8 minutes testing and coding* time per injector

• Dynamic and static measurement of the actual overflow

• Dual-Coil HEUi Injector testing capable

EUi/EUp Testing & Coding* (requires HK1400A Cambox)

• 6-10 minutes testing and coding* time per injector

• Capable for all EU6 technologies

• Expandable to Future Systems

CGL - Authorized Continental / VDO “Blind-Lift” Measurement of Piezo-Stack

Input frequency	50-60 Hz
Number of phases	3 P/PE
Speed range	0 – 6,500 rpm 12.5 HP
Powerful Motor with thermal protection	-
Maximum operating ambient temperature	50 ^oC
Base to axis center height	125 mm
High Pressure system Max Pressure	2800 Bar
Supply pump pressure	10 - 800 kPa
Test oil tank	38 L
Waste Oil tank	15 L
Dimensions (W x D x H) / Weight	750 x 700 x 1610 mm / 465 kg

Additional options

Description

HK1400A-CZ

All makes Hartridge HK1400A Cambox Base Unit Only
(Optionals: Available Adapters for All Makes and Types)

15 600.00 EUR
GDI CAMBOX

GDi HP Pumps Cambox for reciprocating motion (not for rotary) pumps only. Standard Cambox fitting is included for P/N Bosch 0261520036, 0261520042, HTC/ 03C127025, HF-S853A01 or similar. [REQUIRED MTBR-GDp SW N/A]

2 200.00 EUR
GDi-HP01

GDi HP Pumps rotary flange kit (Flange & Coupling)

585.00 EUR
EZO-KIT|X

Use the only Easy Oil Supply unit to change the Cam position fast and oil mess-fee

950.00 EUR
HK1400A-(adapters)

Hartridge HK1400A Optional Adapters Required for All Makes and Types

7 625.00 EUR

Machine Add-ons

SPAR.V2

Piezo stack air remover kit. Used for professional repair & re-assembly of piezo injector valves ( SPAR.V2 ) [REQUIRES CZ-008494]

2 500.00 EUR

Software Activations

Optional&Kits

Diesel Injector Harness & Connectors

CRIN Adapters for Common Rail Injectors

Adapters for GDi Injectors

Adapters for HEUI Injectors

HUS.01.B

CAT 7.3L/3126

624.00 EUR
HUS.02.B

CAT C7-C9

553.00 EUR
HUS.03.B

ISUZU TROOPER

624.00 EUR
HUS.04

FORD POWER STROKE 6.0L FORD POWER STROKE 6.0L
(REQUIRES CZ-007189 & EXT.50 x2 Pcs)

480.00 EUR
HUS.06

CAT3408/3412 (REQUIRES UAC.01)

845.00 EUR
HEUI.KIT.M3

HEUI HYDRAULIC KIT ( 1 SLOT )

650.00 EUR
HUS.14

ADAPTER HUS.14 FOR FORD INJECTOR POWER STROKE 6.0L

845.00 EUR
HUS.15

ADAPTER HUS.15 FOR FORD INJECTOR POWER STROKE G2,9

845.00 EUR

Calibration Oils & Fluids

D20L-ISO

CALIBRATION OIL ISO4113 FOR ALL DIESEL COMMON RAIL BENCHES w/ ELECTRONIC MEASUREMENT & TESTING UP TO 2800BAR [SUCCESSOR: B20L-AW2]

185.00 EUR
G4L-ISO

GDi GASOLINE TESTING FLUID FOR ELECTRONIC MEASUREMENT & TESTING UP TO 850BAR - GD/GDU SERIES [4LT] [Old: RD4L/R4L]

65.00 EUR
G25L-ISO

GDi GASOLINE TESTING FLUID FOR ELECTRONIC MEASUREMENT & TESTING UP TO 850BAR - GD/GDU SERIES [25LT] [SUCCESSOR: RD25L]

315.00 EUR
Y4L

ULTRASONIC CLEANING SOLVENT [4LT]

60.00 EUR
Y25L

ULTRASONIC CLEANING SOLVENT[25LT]

300.00 EUR

Trolley

CZ-002380

CARBON ZAPP TROLLEY V.1

1 287.00 EUR
CZ-002507

TROLLEY RACK BASE FOR CRP/CAMBOX ( MAX. 2 Pcs PER TROLLEY )

150.00 EUR
CZ-002587

TROLLEY DRAWER INSERT FOR CRP FLANGE ( MAX. 1 Pc PER TROLLEY )

202.00 EUR
CZ-002765

TROLLEY SIDE RACK FOR HOSES/WIRES ( MAX.2 PER TROLLEY )

254.00 EUR

GDi Optinals

GDi.WIRES-KIT.02

EXCLUSIVE GDi WIRES KIT INCLUDES: BCI.01, BPI.01, DGxS-B, DGxS-C each cde included per piece

300.00 EUR
BFK.01.B

BACK FLUSH KIT (For 1 slot units)

143.00 EUR
CZ-007402

GDi HYDRAULIC KIT FOR 1 SLOT MACHINE

924.00 EUR
CZ-007404

GDi HYDRAULIC KIT FOR 4 SLOT MACHINE

2 280.00 EUR

MTBR EXTRAS

CZ-007357

DESK & HARNESS SELV FOR MTBRX

260.00 EUR
CZ-007358

HYDRAULIC HOSE SIDE PANEL WITH DRAIN FOR MTBRX

390.00 EUR

Ultrasonic Baths

GDA-1

GDi Adapters Set Includes: GDA-1.U, GDA-1.P4, GDA-1.D

0.00 EUR
UB-15S

HEAT CONTROL/ 42KHZ / 1.75L [FOR R & X UNITS REQUIRES EXT.50]

275.00 EUR
UB-15E/110V

SWEEP TECHNOLOGY 31-42KHZ/DEGAS/HEAT/1.5L/ 51x137x100mm-110V (ELMA) [FOR R & X UNITS REQUIRES EXT.50]

730.00 EUR
UB-15E/220V

SWEEP TECHNOLOGY 31-42KHZ/DEGAS/HEAT/1.5L/ 51x137x100mm-220V (ELMA) [FOR R & X UNITS REQUIRES EXT.50]

0.00 EUR
UB-30E

ULTRASONIC BATH STANDARD: HEAT CONTROL/ 2,75L/ 240x137x100mm (ELMA)

780.00 EUR
UB-60E

ULTRASONIC BATH STANDARD: HEAT CONTROL/ 5,75L/ 300x151x150mm (ELMA)

1 350.00 EUR
UB-120E

ULTRASONIC BATH STANDARD: HEAT CONTROL/12,75L/ 300x240x200mm (ELMA) [INCLUDED COVER & BASKET]

2 650.00 EUR
UB-120

ULTRASONIC BATH STANDARD: HEAT CONTROL/12,75L/ 300x240x200mm (ELMA) [WITHOUT COVER & BASKET]

2 450.00 EUR
UB-450E

HEAT CONTROL/ 45L/ 500x300x300mm (ELMA)

3 745.00 EUR

Total

0.00 EUR
